GV101WXM-N12 Information:
|
Hom |
BOE |
|
Qauv Lub Npe |
GV101WXM-N12 |
|
Zaub Loj |
10.1 hli |
|
Hom vaj huam sib luag |
ib -Si TFT-LCD, LCM |
|
Kev daws teeb meem |
1280 (RGB) × 800, WXGA, 16:10 |
|
Pixel Hom ntawv |
RGB Vertical Stripe |
|
Qhov chaw tso saib |
216.576 × 135.36 hli (H × V) |
|
Vaj huam sib luag hnyav |
TBD |
|
Daim Ntawv Qhia Loj |
228.6 × 149.2 × 6 hli (H × V × D) |
|
Nto |
Antiglare (Haze 25%), Hard txheej (6H) |
|
Brightness |
400 cd / m² (Typ.) |
|
Qhov sib piv piv |
900: 1 (Typ.) (TM) |
|
Saib lub kaum sab xis |
85/85/85/85 (Typ.)(CR Ntau dua lossis sib npaug rau 10) |
|
Zaub hom |
ADS, Feem ntau Dub, Transmissive |
|
Saib Kev Qhia |
Symmetry |
|
Teb Sijhawm |
30 (Typ.)(Tr+Td) |
|
Zaub Xim |
16.2M, 50% NTSC |
|
Daim ntawv thov |
Kev lag luam |
|
Ntau zaus |
60 Hz |
|
Kov npo |
PCAP, I² C |
|
Lub zog Cons. |
4.2W (Max.) |
|
Lub teeb Source |
WLED, 30K teev, Nrog LED tsav tsheb |
|
Hom teeb liab |
LVDS (1 ch, 8-ntsis), Connector 40 pins |
|
Kev siv hluav taws xob |
3.3V (Typ.) |
|
Max. Kev ntsuas |
Cia Temp . -30 ~ 70℃Kev khiav hauj lwm Temp . -20 ~ 70 degree |
GV101WXM-N12Kev them nyiaj:
Rau koj txoj kev yooj yim, ntau txoj kev them nyiaj muaj, suav nrog PayPal, daim npav rho nyiaj loj (Visa, MasterCard, Discover), thiab Alibaba kev them nyiaj ua lag luam. Thaum kuaj xyuas, koj tuaj yeem xaiv tus qauv thiab xim xaiv (yog tias tsim nyog) los ntawm cov ntawv qhia zaub mov.
Koj tuaj yeem hloov kho lossis thim koj qhov kev txiav txim ua ntej xa khoom xa tuaj. Thov hu rau peb thiab peb yuav pab koj ua tiav cov txheej txheem cuam tshuam. Thaum lub parcel tau xa tuaj, kev txiav txim tshem tawm tsis muaj ntxiv lawm. Yog tias qhov xwm txheej no tshwm sim, thov hu rau peb, thiab peb yuav ua haujlwm ua ke los nrhiav kev daws teeb meem.
GV101WXM-N12 Khoom siv:
GV101WXM-N12 tiv tauj peb:
Tel: +8618575563918
E-mail:sales@yongs-hk.com
Yog tias koj muaj lus nug txog kev hais lus lossis kev koom tes, thov koj xa email tuaj rau peb ntawm sales@yongs-hk.com lossis siv daim ntawv nug nram qab no. Peb tus neeg muag khoom yuav tiv tauj koj hauv 24 teev. Ua tsaug rau koj txaus siab rau peb cov khoom
GV101WXM-N12 FAQ:
Q: Kuv yuav tau txais kuv cov khoom ntev npaum li casGV101WXM-N12?
A: Feem ntau hais lus, Nws yuav siv sijhawm 3-8 hnub rau koj txhais tes los ntawm DHL / FEDEX / UPS / TNT.
Q: Lub warranty ntev npaum li cas?
A: Peb muab 90 hnub warranty.
Q: Koj puas tuaj yeem tshaj tawm kuv qhov kev txiav txim ntawmGV101WXM-N12mus rau tus nqi qis dua hauv daim ntawv them nqi lag luam rau kev lis kev cai?
A: Yog, peb tuaj yeem ua tau. pls qhia peb ua ntej shipping.
Q: Kuv yuav tau txais kuv cov khoom ntev npaum li casGV101WXM-N12?
A: Feem ntau hais lus, Nws yuav siv sijhawm 3-8 hnub rau koj txhais tes los ntawm DHL / FEDEX / UPS / TNT.
Cim npe nrov: gv101wxm-n12 tshiab thawj 10.1 nti 1280 * 800 lcd zaub, Tuam Tshoj, lwm tus neeg, lag luam wholesale, yuav, pheej yig, luv nqi, luv nqi, hauv Tshuag
